Lazily builds collection of reconstructed jets that pass analysis selection. More...
#include <JetBuilder.h>
Public Member Functions | |
| JetBuilder (Dataset &dataset, Options const &options, TabulatedRngEngine &rngEngine, PileUpIdFilter const *pileUpIdFilter=nullptr) | |
| std::vector< Jet > const & | Get () const override |
| Returns collection of jets. | |
| std::vector< Jet > const & | GetRejected () const |
| Returns collection of jets that have been rejected by pileup ID but satisfy other requirements. | |
| void | SetGenJetBuilder (GenJetBuilder const *genJetBuilder) |
| Specifies an object that provides generator-level jets. | |
Private Member Functions | |
| void | AddType1Correction (TLorentzVector const &rawP4, double area, double jecOrig, double jecNew, double jerFactor, double emFraction, double muonFraction) const |
| Adds a contribution to the type 1 correction of missing pt. | |
| void | Build () const override |
| Constructs jets in the current event. | |
| GenJet const * | FindGenMatch (TLorentzVector const &p4, double ptResolution) const |
| Finds matching generator-level jet using JERC definition. | |
| double | GetJerFactor (TLorentzVector const &corrP4, int rngChannel) const |
| Computes momentum scale factor that accounts for JER smearing. | |
| void | ProcessJets () const |
| Constructs collection of jets in the current event. | |
| void | ProcessSoftJets () const |
| Processes soft jets in the corrent event. | |
| bool | SetPileUpInfo (Jet &jet, int index) const |
| Deals with pileup ID for given jet. | |
Private Attributes | |
| GenJetBuilder const * | genJetBuilder_ |
| Non-owning pointer to an object that produces generator-level jets. | |
| PileUpIdFilter const * | pileUpIdFilter_ |
| Non-owning pointer to an object that implements jet filtering based on pileup ID. | |
| double | minPt_ |
| Minimal pt for jets, GeV. | |
| double | maxAbsEta_ |
| Maximal |eta| for jets. | |
| double | minPtType1Corr_ |
| Minimal (corrected) pt for jets to be used in type 1 correction of missing pt. | |
| bool | ptMissEeNoise_ |
| Whether to apply the EE noise mitigation in missing pt. | |
| bool | ptMissJer_ |
| Whether to propagate JER smearing into missing pt. | |
| bool | ptMissPogJets_ |
| Whether to compute the type 1 correction for missing pt skipping jets with a high EM energy fraction and removing leptons from them. | |
| double | pileUpIdMinPt_ |
| Range of pt, in GeV, where pileup ID is applicable. | |
| double | pileUpIdMaxPt_ |
| std::vector< Jet > | jets_ |
| Collection of jets. | |
| std::vector< Jet > | rejectedJets_ |
| Collection of jets rejected by pileup ID. | |
| bool | isSim_ |
| Indicates whether running on simulation or data. | |
| int | jetIdBit_ |
| Index of the bit with jet ID decision. | |
| JetCorrector | jetCorrector_ |
| Object that computes JEC. | |
| TTreeReaderArray< float > | srcPt_ |
| TTreeReaderArray< float > | srcEta_ |
| TTreeReaderArray< float > | srcPhi_ |
| TTreeReaderArray< float > | srcMass_ |
| TTreeReaderArray< float > | srcArea_ |
| TTreeReaderArray< float > | srcRawFactor_ |
| TTreeReaderArray< float > | srcChEmEF_ |
| TTreeReaderArray< float > | srcNeEmEF_ |
| TTreeReaderArray< float > | srcMuonFraction_ |
| TTreeReaderArray< float > | srcBTag_ |
| TTreeReaderArray< int > | srcId_ |
| TTreeReaderArray< int > | srcPileUpId_ |
| TTreeReaderValue< float > | puRho_ |
|
std::optional < TTreeReaderArray< int > > | srcHadronFlavour_ |
|
std::optional < TTreeReaderArray< int > > | srcPartonFlavour_ |
|
std::optional < TTreeReaderArray< int > > | srcGenJetIdx_ |
| TTreeReaderArray< float > | softRawPt_ |
| TTreeReaderArray< float > | softEta_ |
| TTreeReaderArray< float > | softPhi_ |
| TTreeReaderArray< float > | softArea_ |
| TTreeReaderArray< float > | softMuonFraction_ |
Lazily builds collection of reconstructed jets that pass analysis selection.
Reads parameters from sections jets and ptmiss of the master configuration. The latter specify how jets contribute to the type 1 correction of missing pt.
Jets are checked against the kinematical selection specified in the configuration, as well as jet ID. Selection on pileup ID is applied if the corresponding filter object is provided to the constructor.
Systematic variations in jets are implemented with the help of JetCorrector, which also applies JER smearing. To follow the standard smearing algorithm, this builder needs to be made aware of generator-level jets via method SetGenJetBuilder.
Jet with corrected pt > 15 GeV (the exact meaning depends on the configuration) are aggregated for GetSumMomentumShift to be used for the type 1 correction of missing pt. The details are controlled by section ptmiss of the master configuration. The following fields are supported:
jer Boolean indicating whether JER smearing should be propagated into missing pt.pog_jets Optional boolean; defaults to false. Requests that jets with a high EM energy fraction are skipped from the computation and constituent muons are subtracted from the remaining jets. This is how the standard type 1 correction is computed.fix_ee_2017 Optional boolean; defaults to false. Indicates whether the EE noise mitigation should be applied. Jets that geometrically overlap with other objects (as checked with IsDuplicate) are never propagated into the missing pt. | void JetBuilder::AddType1Correction | ( | TLorentzVector const & | rawP4, | |
| double | area, | |||
| double | jecOrig, | |||
| double | jecNew, | |||
| double | jerFactor, | |||
| double | emFraction, | |||
| double | muonFraction | |||
| ) | const [private] |
Adds a contribution to the type 1 correction of missing pt.
| [in] | rawP4 | Raw four-momentum of the jet. |
| [in] | area | Area of the jet. |
| [in] | jecOrig | The full JEC applied during production of NanoAOD. |
| [in] | jecNew | The full JEC applied in the analysis, including the JEC systematic variation. |
| [in] | jerFactor | Scale factor representing JER smearing on top of the full JEC. |
| [in] | emFraction | Total (neutral and charged) electromagnetic energy fraction in a jet. A non-positive value disables the corresponding cut. |
| [in] | muonFraction | Fraction of (raw) jet energy carried by muons. |
Implements the type 1 correction according to the full - L1 scheme. The full correction includes JEC systematic variations (so that they are propagated into missing pt) and, depending on the value of ptMissJer_, JER smearing.
If ptMissPogJets_ is true, jets with a high EM energy fraction are skipped and constituent muons are removed. This mimics the standard procedure to compute the type 1 correction.
If the EE noise mitigation is enabled, soft jets in the EE are excluded from this procedure. At the same time these jets are used to undo some of the contributions in the starting ptmiss.
| void JetBuilder::Build | ( | ) | const [override, private] |
Constructs jets in the current event.
Actual work is delegated to ProcessJets and ProcessSoftJets.
| GenJet const* JetBuilder::FindGenMatch | ( | TLorentzVector const & | p4, | |
| double | ptResolution | |||
| ) | const [private] |
Finds matching generator-level jet using JERC definition.
Returns a nullptr if no match is found within the allowed cone.
| double JetBuilder::GetJerFactor | ( | TLorentzVector const & | corrP4, | |
| int | rngChannel | |||
| ) | const [private] |
Computes momentum scale factor that accounts for JER smearing.
| [in] | corrP4 | Corrected four-momentum of the jet. |
| [in] | rngChannel | Channel for the random number generator. Should be set to the index of the jet in the current event. |
| std::vector<Jet> const& JetBuilder::GetRejected | ( | ) | const |
Returns collection of jets that have been rejected by pileup ID but satisfy other requirements.
Filled only if a PileUpIdFilter has been provided.
| void JetBuilder::ProcessSoftJets | ( | ) | const [private] |
Processes soft jets in the corrent event.
These are jets from branches CorrT1METJet_*.
| void JetBuilder::SetGenJetBuilder | ( | GenJetBuilder const * | genJetBuilder | ) |
Specifies an object that provides generator-level jets.
Generator-level jets are used for JER smearing. However, if no such object is given, stochastic version of the smearing will be performed. When given, the object must have an approriate life time.
| bool JetBuilder::SetPileUpInfo | ( | Jet & | jet, | |
| int | index | |||
| ) | const [private] |
Deals with pileup ID for given jet.
Sets data members in jet related to pileup ID and applies the filtering on pileup ID if it is enabled.
| [in,out] | jet | Jet to be checked and updated. |
| [in] | index | Index of the jet in the source branches. |
GenJetBuilder const* JetBuilder::genJetBuilder_ [private] |
Non-owning pointer to an object that produces generator-level jets.
May be nullptr.
PileUpIdFilter const* JetBuilder::pileUpIdFilter_ [private] |
Non-owning pointer to an object that implements jet filtering based on pileup ID.
May be nullptr.
bool JetBuilder::ptMissPogJets_ [private] |
Whether to compute the type 1 correction for missing pt skipping jets with a high EM energy fraction and removing leptons from them.
This is how the standard type 1 correction is computed.
